--- SimFab offers wide range of modular flight simulation pits with high level of fidelity, realism and immersion. While all our pits, attachments and brackets are designed, replicating real aircrafts layout we take in consideration optimal comfort, modularity and full compatibility with all established brands and controls makers on the current market.
imFab modular flight pit concept starts with several basic models covering the essentials at most affordable budget, without compromising quality and craftsmanship.
Base models are suitable for flight sim pilots entering the air field of flight simulation and looking to give it a try at affordable cost. Each of our models has modular design, all scalable and interchangeable with one another, whether preferred setup is focused on combat, general aviation, space sim or hybrid of all.
Our base models are purposed for type of flight simulation as well as types of flight controls sharing similar attachment design. Each of the three base models flight sim pits is scalable by purchasing individual modules.
Each modular flight pit is also interchangeable with one another, offered as add-on kits.
DCS Edition Modular Flight Pit
--- Modular combat flight sim pit “DCS edition”: DCS edition modular flight pit is dedicated combat pit purposed for mostly DCS World modules. Base package is equipped with the following essentials: seat with chassis, side by side HOTAS style mount brackets for stick and throttle, rudder pedal plate, center stick lower mount bracket with ability to mount sticks with grip extension or cyclic for heli sim.
Compatible controls for DCS edition pit base model:
1. Thrustmaster Warthog stick and throttle
2. VirPil Sticks, throttles, control panels
3. VKB Gunfighter stick
4. WinWing stick bases and Orion throttle
Optional add-on modules to flight pit model 2:
*Certain add-ons require our “Advanced modular side mount kit” a.k.a AMSM
Configuration #10 (to be released in March, 2023)
Bracket kit allows shared mounting of multiple controls on either side of user’s cockpit or flight pit. Individual adjustment and quick “hot swap” of controls enhances the modular concept of SimFab basic design.
Configuration #7: Stick grip extension compatible with Thrusmtster Warthog, Virpil and WinWing sticks
Configuration #11: WinWing Super Taurus throttle bracket assembly kit (requires and part of AMSM package)
Configuration #10: WinWing take-off/combat panel, also compatible with VirPil control panels #1 and #2 (requires and part of AMSM)
Configuration #11: universal helicopter collective bracket assembly compatible with both WinWing and VirPil collectives.
Configuration #12: MFDs bracket assembly: F-16 and alike (2+1) or F-18 and alike (3+1)
Configuration #13: Additional side mounted control box or throttle bracket assembly kit (Requires AMSM)
Configuration #14: Additional stick plate assembly kit (dual stick setup)
MSFS Edition Modular Flight Pit
--- Modular flight pit for civil and general aviation “MSFS edition”: MSFS edition base model is dedicated to civil, general and commercial aviation sim. Essential components include: seat with chassis and mounting brackets for yoke, throttle quadrant, rudder pedals.
MSFS edition modular flight pit base model is compatible with the following controls:
1. Honeycomb Alpha yoke and Bravo throttle quadrant
2. Turtle Beach Velocity One yoke and throttle quadrant
3. Logitech/Saitek yoke and single/dual throttle quadrant with optional Flight Velocity Trim Wheel
4. CH Products yoke and throttle quadrant
Optional add-on brackets:
Configuration #8: Thrustmaster Boeing yoke and throttle quadrant mounting bracket kit.
Configuration #9: Thrustmaster Boeing yoke bracket only.
Hybrid Edition Modular Flight Pit
--- Flight sim pit “Hybrid edition” use with civil, combat and space sim. Flight sim pit hybrid edition is a combination of combat and civil aviation as well as space sim gaming. Essentials cover the following: Seat and chassis with side by side mounting brackets for stick and throttle, rudder pedal plate, standard mounted center stick mounting bracket. Hybrid modular flight pit base model is compatible with the following controls:
1. Thrustmaster HOTAS T.Flight stick and throttle
2. Thrustmaster T16000M stick and throttle
3. Thrustmaster TCA AirBus
3. Logitech/Saitek X52, X52 Pro, X56
4. VKB Gladiator Stick
5. CH Products stick and throttle
6. Hori stick and throttle
DD Modular Racing Sim Cockpit
--- Materials and choice of fabrication
Full size ergonomic seat with sliders and recliner mechanism. Our seats are full size made with high quality materials: steel internal frame, thick layer of cold cured foam, durable, breathable, and long-lasting upholstery fabric material. Seats are offered in six vibrant colors of choice: black, red, blue, orange, green and yellow. In addition we offer limited edition colors as well as customer choice custom color as per pantone chart. Our patented seat base design includes removable foam insert for optional lowered center flight stick or heli cyclic mount bracket. Slanted shaped cutout allows full motion of the stick without protruding into the seat foam while being at correct arm reach distance.
Our preferred choice of framing and mounting brackets is 1.8 -2mm thick carbon steel telescopic tubing. While extruded aluminum is widely popular, we find carbon steel tubing more customizable material as far as fabrication, welding and manipulating (bending, forming cutting). Well fabricated material shows the craftsmanship and quality of hand work while extruded aluminum is more of a do-it-yourself material which comes at higher cost and limited fabrication properties. Our adapter plates are made of 4-6mm thick, 5052 alloy aluminum plate.
Finish: Our metal parts are finished with sandblasted and then zinc plated treatment or durable powder coating. Our local fabrication shop in Florida offers customization of specific brackets or powder coating color per customer’s request.
Featuring single monitor stand with overhead and sub mount monitor mount brackets. Front surround speaker trays. Samsung G9 49" ultrawide main and overhead monitors. 24" touchscreen sub monitor, Logitech speakers
Complete multipurpose and modular hybrid rig with modular sim racing and flight sim capabilities. Complimented with standalone single monitor mount stand.
Featuring: Fanatec sim racing gear, VirPil flight sim gear, Samsung G9 49" ultra wide monitor, Logitech surround speakers, keyboard and mouse, Buttkicker shaker.
SimFab presenting OpenWheeler Gen3 sim racing cockpit. Feauturing the following peripherals: *red racing seat, Butkicker LFE, Fanatec racing wheel, pedals and manual shifter, Thrustmaster Sparco handbrake / sequential shifter.
* Racing seat is available in six vibrant colors of choice: red, blue, orange, green, yellow, all black
OpenWheeler Gen3 platform is designed as a modular and versatile ecosystem complimented by various add-on accessories for optimum immersion, comfort and overall enjoyable experience by young, adult and senior members of the household.
Our flight sim options cover every aspect of flight simulation with ergonomic design, rigid mounting brackets, adjustment and full compatibility. Flight sim configurations are suitable for combat, space sim as well as commercial and recreational flight simulation.
Flight Configuration #1, compatible with:
Logitech (Saitek) X-56, Logitech (Saitek) X-52, Thrustmaster T16000M, Thrustmaster Airbus, Thrustmaster T.Flight, Hori, CH Products, VKB Gladiator
Flight Configuration #2, compatible with:
Thrustmaster Warthog, VirPil, WinWing, VKB Gunfighter
Configuration #1: HOTAS side by side mount, universal fit for all combat or commercial aviation flight controls with wide bases
Configuration #2: HOTAS side by side mount, universal fit for all combat controls with removable stick grips: Thrustmaster Warthog, VirPil, WinWing, VKB
Configuration #3: Standard center mounted stick over knees height
Configuration #4: Dedicated rudder pedal plate. Compatible and direct bolt on with all rudder pedals on the market: Logitech-Saitek, Thrustmaster, VirPil, CH Products, VKB, MFG Crosswind, Slaw-Device
Configuration #5: Civil and commercial aviation flight sim package.
Configuration #6: Lower mounted center stick for sticks with added grip extension or helicopter sim cyclic.
Configuration #7: Flight stick grip extension. Compatible with Thrustmaster Warthog, VirPil and WinWing flight sticks.
Versatile sim racing options
Generic USB handbrake mount bracket, independently mounted and paired with any major brand manual shifter: Logitech, Thrustmaster or Fanatec.
Thrustmaster Sparco handbrake independantly mounted, with combination of any major brand manual shifter: Thrustmaster, Logitech, Fanatec
Independantly mounted Thrustmaster Sparco handbrake/sequential shifter or dual Sparco mode
Adapter plate for Fanatec handbrake with optional e-brake mode
FOR ADDED IMMERSION
4 point harness VR ready
Shaker bracket single or dual mount.
Modular design with precise adjustment ability to align monitors to perfection. Monitor mount stands that actually work. Available in single, triple or any odd number of monitors added horizontally or vertically. Our patented design of monitor mounts covers any size monitors or TV sets from 24" to 65".
Keyboard tray kit
FOR ADDED COMFORT
Seat lift kit
Lumbar and headrest support pillows
Seat protective cover in color of choice
Seat frame rear support extension. Use your seat as a general lounge or gaming chair, recline all the way back and enjoy your chill time.
Pedal plate dead pedal support. Relax or left foot while doing long sim racing sessions.
Arm rest kit
